6a.
MOTOR SHAFT
HOW TO
HOW TO
4. TO REPLACE BELT OR
BRUSHROLL: Slide belt onto
motorshaft.
5. Place new belt in area of brushroll
without bristles
BELT OR BRUSHROLL:
REMOVAL & REPLACEMENT
6. With new belt in place, pull and
slide brushroll into nozzle making
sure that the brushroll end caps
are in the correct orientation (6a
inset). Rotate brushroll manually to
make sure belt is properly aligned.
7. Reattach nozzle guard.
