23
5 Maintenance
GB
5.2 Fitting the filter
1. Put the permanent textile filter back into
the dust container (Fig. 11).
5.3 Assembling the appliance
1. Fit the dust container in such a way that
the groove in the bottom of the container
(Fig. 12/arrow) engages the tab on the
bottom side of the motor unit.
2. Then fold the dust container back into
place, pushing firmly on the top side
(Fig. 13/arrow) You must feel and hear it
clicking into place.
3. Check that the dust container is fitted se-
curely.
Never operate the appliance without the filter
correctly fitted inside the dust container.
Otherwise, the motor might be damaged.
The permanent textile filter is designed so
that it only fits in the correct position.
