16
HOW TO
BELT OR BRUSHROLL:
REMOVAL & REPLACEMENT
8.
Secure by aligning the three (3)
tabs in the base slots.
9.
Replace all five (5) screws to
secure nozzle guard.
SLOTS
TABS
