1592022550 Quick reference guide IC100CX GB rel.1.0 03/03/2008 Page 27 di 39
CF20 RL4 configuration of the relay 4
0 = Alarm relay
1 = compressor 1 capacity step
2 = compressor 2
3 = ON/OFF ventilation
4 = reversing valve
5 = anti-freezer heaters / integration heater n.1
6 = solenoid valve on water circuit
7 = solenoid valve on water circuit only for heat pump
8= anti-freezer heaters / integration heater n. 2
9 = evaporator water pump / supply fan (air / air unit)
10= condenser water pump
0 10
CF21 RL5 configuration of the relay 5
0 = Alarm relay
1 = compressor 1 capacity step
2 = compressor 2
3 = ON/OFF ventilation
4 = reversing valve
5 = anti-freezer heaters / integration heater n.1
6 = solenoid valve on water circuit
7 = solenoid valve on water circuit only for heat pump
8= anti-freezer heaters / integration heater n. 2
9 = evaporator water pump / supply fan (air / air unit)
10= condenser water pump
0 10
CF22 4mA / 0,5V corresponding to the pressure value of the
transducer
0.0
0
50.0
725
Bar
Psi
Decimal
integer
CF23 20mA / 5V corresponding to the pressure value of the
transducer
0.0
0
50.0
725
Bar
Psi
Decimal
integer
CF24 Pb1 Offset -12.0
-21.6
12.0
21.6
°C
°F
Decimal
integer
CF25 Pb2 Offset -12.0
-21.6
12.0
21.6
°C
°F
Decimal
integer
CF26 Pb3 Offset -12.0
-21.6
-12
-174
12.0
21.6
12
174
°C
°F
Bar
Psi
Decimal
Integer
Decimal
integer
CF27 Pb4 Offset -12.0
-21.6
12.0
21.6
°C
°F
Decimal
integer
CF28 Chiller or Heat Pump configuration
0= chiller and heat pump selected by keyboard
1= chiller and heat pump selected by digital input
2= chiller and heat pump selected by probe
3= only chiller unit
4= only heat pump unit
0 4
CF29 Automatic Changeover Setpoint -50.0
-58
110
230
°C
°F
Decimal
integer
CF30 Differential for functioning mode 0.0
0
25.0
45
°C
°F
Decimal
integer
CF31 Chiller or Heat pump key configuration
0= chiller / heat pump
1= chiller / heat pump
0 1
