DJ-Tech Mixer one - Page 22

I/O FUNCTION MIDI CODE
MIDI CODE
+CHANNEL
FUNCTION
CODE
ACTION
29 O
RIGHT
MID ROTARY
0B BY2 17H 00~7F
30 O
RIGHT
LO ROTARY
0B BY2 18H 00~7F
31 O
RIGHT CHANNEL
FADER
0B BY2 19H 00~7F
32 O
RIGHT HI
ROTARY
MIDDLE
09 9Y2 16H
MIDDLE IN:7F
MIDDLE OUT:00
33 O
RIGHT MID
ROTARY MIDDLE
09 9Y2 17H
MIDDLE IN:7F
MIDDLE OUT:00
34 O
RIGHT LO
ROTARY MIDDLE
09 9Y2 18H
MIDDLE IN:7F
MIDDLE OUT:00
35 I RIGHT MID LED 09 9Y1 01H 7FH：ON／00H：OFF
36 I RIGHT HI LED 09 9Y1 02H 7FH：ON／00H：OFF
37 I RIGHT PFL LED 09 9Y1 03H 7FH：ON／00H：OFF
38 I RIGHT LO LED 09 9Y1 04H 7FH：ON／00H：OFF
39 I INVERSE LED 09 9Y3 05H 7FH：ON／00H：OFF
40 I LEFT HI LED 09 9Y2 06H 7FH：ON／00H：OFF
41 I LEFT PFL LED 09 9Y2 07H 7FH：ON／00H：OFF
42 I LEFT LO LED 09 9Y2 08H 7FH：ON／00H：OFF
43 I LEFT MID LED 09 9Y2 09H 7FH：ON／00H：OFF
BY3(*NOTE2)1FH(*NOTE2)
44 I LEFT LEVEL LED 0B
BY1(*NOTE3)22H(*NOTE3)
00~7F(*NOTE4)
BY3(*NOTE2)20H(*NOTE2)
45 I RIGHT LEVEL LED 0B
BY2(*NOTE3)23H(*NOTE3)
00~7F(*NOTE4)
K NOTE1
EXAMPLE：
1. WHEN: DECKA CHANGE TO DECKC => 95 87 7F
THEN: DECK MIDDLE CHANGE => 97 A5 7F
WHEN: DECKC CHANGE TO DECKA => 97 85 7F
THEN: DECK MIDDLE CHANGE => 95 A7 7F
2. DECKB CHANGE TO DECKD => 96 98 7F
3. DECKD CHANGE TO DECKB => 98 96 7F
K NOTE2: WHEN PFL/MASTER SW= MASTER
K NOTE3: WHEN PFL/MASTER SW=PFL
K NOTE4
LEVEL LED CODE：
00~11 => 0 => ALL LED OFF
12~23 => 12 => 1 LED ON
24~35 => 24 => 2 LEDS ON
36~47 => 36 => 3 LEDS ON
．．．．．
120~127 => 120 => ALL LEDS ON
KEY WORD
