ROBOMASTER S1
User Manual
Wide Infrared Units
Effective Range
[4]
3 m (in indoor lighting conditions)
Effective Width 360° (in indoor lighting conditions)
Hit Detector
Detection Requirements
For the hit detector to be activated, the following
conditions must be met: Gel bead diameter ≥ 6mm,
launching speed ≥20 m/s, and the angle between the
hit direction and hit detector plane is no less than 45°.
Maximum Detection Frequency 15 Hz
Intelligent Battery
Capacity 2400 mAh
Maximum Charging Voltage 12.6 V
Nominal Charging Voltage 10.8 V
Battery Type LiPo 3S
Energy 25.92 Wh
Battery Life (in use)
35 mins (measured at a constant speed of 2.0 m/s on
a at surface)
Battery Life (on standby) Approx. 100 minutes
Weight 169 g
Operating Temperature Range -10 to 40 °C (14 to 104 °F)
Charging Temperature Range 5 to 40 °C (41 to 104 °F)
Maximum Charging Power 29 W
Charger
Input 100-240 V, 50-60 Hz, 1 A
Output Port: 12.6 V=0.8 A or 12.6 V=2.2 A
Voltage 12.6 V
Rated Voltage 28 W
Gel Bead
Diameter 5.9- 6.8 mm
[5]
Weight 0.12-0.17 g
[5]
App
iOS iOS 10.0.2 or later
Android Android 5.0 or later
Others
Recommended Routers
TP-Link TL-WDR8600; TP-Link TL-WDR5640 (China)
TP-Link Archer C7; NETGEAR X6S (International)
Recommended outdoor power supply
solution for routers
Portable laptop charger (with the same input power of
the router)
