4
3. Place the charging hub on a at and stable surface when in use.
Make sure the device is properly insulated to prevent re hazards.
4. DO NOT attempt to touch the metal terminals on the charging hub.
5. Clean the metal terminals with a clean, dry cloth if there is any
noticeable buildup.
Introduction
The DJI WB37 Battery Charging Hub (USB-C) is designed to charge
up to two Intelligent Batteries when using with a compatible charger
and supports USB Power Delivery protocol. The charging hub will
intelligently charge batteries in sequence according to the battery
power levels from high to low.
Usage
The DJI 65W Portable Charger and Intelligent Battery (WB37-4920mAh-
7.6V) are used for illustration.
1. Insert the batteries into the charging hub until there is a click, connect
the charger to the power port on the charging hub, and connect the
charger to a power outlet (100-240 V, 50/60 Hz). (Figure A)
2. The batteries will be charged in sequence according to the power
levels from high to low. The status LEDs will glow solid white after
the corresponding battery is fully charged. Remove the battery
from the charging hub.
Users can also use an FCC/CE-certified charger that
supports USB Power Delivery protocol. It is recommended
that the charger has a power capacity of at least 55 W and a
current capacity of at least 3.7 A for optimal charging.
Status LEDs Descriptions
Each battery port has its corresponding status LED array.
Charging Status
Status LEDs in array blink
quickly successively
The battery in corresponding battery
port is being charged using fast
charger
