Assembly instruction SYSTEM CADO
®
(ENG)
INSTALLING SUSPENSION RAILS
1. Place the first spacer vertically at the desired height,
indicating the position of the top and bottom of the panel.
2. Place the first suspension rail in the lowest hole of the
spacer, and fasten the rail to the wall with a screw. Do not
tighten the screw completely.
3. Using a level, adjust suspension rail until it is level and fasten
it with the second spacer. Install remaining screws and tighten
the first screw.
4. For the remaining suspension rails repeat step 2 – 3.
Remove the 2 spacers, when all suspension rails have been
mounted.
5. For installation of more than 2 panels, mount a further
set of suspension rails in direct extension of the first rails by
repeating step 1 – 4.
