Part List
NO. DESCRIPTION Q'TY NO. DESCRIPTION Q'TY
1 BASE FRAME 1 36 #8*16MM SCREW 4
2 UPRIGHT TUBE 1 37 M8*18MM SCREW 8
3
FIX HANDLEBAR （L）
1
38 M8*25MM SCREW 2
4
FIX HANDLEBAR （R）
1
39 M8*15mm ALLEN HEAD SCREW 14
5 UPPER SWIVEL HANDLE BAR (L) 1 40 M8*25mm ALLEN HEAD SCREW 4
6 UPPER SWIVEL HANDLE BAR (R) 1 41 M8*20mm ALLEN HEAD SCREW 10
7 LOWER SWIVEL HANDLE BAR (L) 1 42 M8*56mm ALLEN HEAD SCREW 2
8 LOWER SWIVEL HANDLE BAR (R) 1 43 M8*118mm ALLEN HEAD SCREW 4
9 PEDAL TUBE (L) 1 44 M8*15mm HEX HEAD BOLT 2
10 PEDAL TUBE ( R ) 1 45 M8*52MM HEX HEAD BOLT 1
11 OUTER PEDAL POST ( L ) 1 46 M6*18MM HEX HEAD BOLT 4
12 OUTER PEDAL POST ( R ) 1 47 M8*25MM HEX HEAD BOLT 1
13 FRONT FOOT 1 48 M8 CURVE WASHER 6
14 MIDDLE FOOT 1 49 M10*24*0.3T NYLON WASHER 2
15 CROSS BAR OF RAIL 1 50 M5*16*1.5 WASHER 8
16 RAIL 2 51 M8*16*1.2 WASHER 2
17 CROSS FRAME 2 52 M8*16*1.2 WASHER 28
18 MAGNETIC HOLDER BRACKET 1 53 M8*22*1.5T WASHER 1
19 JOCKEY WHEEL BRACKET 1 54 M8*28*2.0T WASHER 2
20 AXLE FOR PULLEY 1 55 M8*38 *2.0TWASHER 4
21 AXLE SUPPORT 1 56 M10*21*2.0T WASHER 2
22 MAGNETIC HOLDER 1 57 M10*22*1.5T WASHER 4
23 WASHER FOR PEDAL 2 58 M5 SPRING WASHER 8
24 ADJUST FEET BRACKET 4 59 M6 SPRING WASHER 4
25 AXLE FOR ROLLER 2 60 M8 SPRING WASHER 2
26 FLYWHEEL 1 61 M8 SPRING WASHER 40
27 FLYWHEEL AXLE 1 62 M10 SPRING WASHER 4
28 PEDAL TUBE SHAFT 2 63 NYLOC NUT M6 5
29 M5*20mm SCREW 8 64 NYLOC NUT M8 2
30 M5*10mm SCREW 8 65
3/8"*9T WH NUT 2
31 M6*10MM SCREW 4 66
3/8"*7T WH NUT
2
32 M3*10MM SCREW 1 67 TURNING PLATF COVER 2
33 M4*20MM SCREW 1 68 TURNING PEDAL 2
34 M5*12MM SCREW 9 69 ROUND END CAP FOR22.2TUBE 2
35 M5*50MM SCREW 4 70 PLUG AXLE SUPPORT 6
