Why is the Laser LED Green and Status LED Red on my DKT Comega OFA-CCS Amplifier?
If the Laser LED is green and the Status LED is red, the optical output power of your DKT Comega Amplifier may not meet the specified output power. Check the Laser ON/OFF state on the Laser Control menu to resolve this issue.
What to do if Laser LED is Red and Status LED is Red on DKT Comega OFA-CCS?
If the Laser LED and Status LED are both red on your DKT Comega Amplifier, it indicates that the optical input power of the EDFA does not meet the minimum requirement. First, measure whether the optical input power from the optical source or transmitter satisfies the minimum optical input power condition. If it does, clean the surface of the optical input connector.
What to do if Laser LED changes from Green to Red and Status LED changes from Yellow to Red on DKT Comega OFA-CCS Amplifier?
If the Laser LED changes from Green to Red and the Status LED changes from Yellow to Red on your DKT Comega Amplifier, the internal temperature of the Pump Laser Diode of the EDFA is out of the specified range. It requires either adjustment or replacement.
How to fix Laser LED Green and Status LED Yellow on DKT Comega OFA-CCS Amplifier?
If the Laser LED is green and the Status LED is yellow on your DKT Comega Amplifier, the capability of the Pump Laser Diode may have degraded, or it could be out of order. The EDFA needs to be repaired or replaced.
General| Brand | DKT Comega |
|---|---|
| Model | OFA-CCS series |
| Category | Amplifier |
| Language | English |
Critical safety and handling precautions for installation and power.
ESD precautions and importance of proper grounding for safety.
Laser safety precautions, warnings, and compliance standards.
Connecting power supply for 1U and 2U shelves.
Explains the meaning of different LED states (LOS, LOP, BIAS, TEMP, POWER, FAN).
Navigating and operating the EDFA using the LCD menu and switches.
Controlling EDFA operational state (ACT/DEACT) via Provision menu.
Controlling optical output power (Laser ON/OFF) and Buzzer settings.
Monitoring and controlling EDFA via Ethernet/COM port using CLI.
Lists CLI commands, descriptions, and execution privileges.
Setting up SNMP, trap settings, and communities.
Setting up IP, Subnet mask, and Gateway addresses.
SNMPv1, v2c setup, communities, and trap settings.
Monitoring and controlling EDFA via a web browser.
Viewing EDFA status and data on the monitoring page.
Viewing and modifying alarm thresholds via the parameter page.
Adjusting various control settings via the web GUI.
Displaying recorded events and alarms on the event log page.
Setting IP, subnet, gateway, and user passwords.
Setting SNMP trap IPs, enable/disable, and communities.
Precautions and checks before performing performance tests.
Step-by-step procedure for measuring EDFA performance.
Testing LOS alarm and buzzer functionality.
Identifying and resolving problems based on symptoms.
Details alarm events, LED states, and causes for troubleshooting.
