8
Parts List Hi-Cap 40 Grain Cleaner
Bearing Revisions
Reference Part Quantity
Number Number Description Needed
1 103C0025 Extension Spring, Belt Tightener 1
2 202B0046 Belt Tightener, Drum Drive 1
3 202B0050 Bearing Mount Extension Bracket 2
4 202B0051 Pivot Bolt, Belt Tightener Bracket, 3/8" 2
5 202B0052 Spring Tension Bracket 1
6 202B0063 Double Bearing Weldment 1
7 202B0064 Double Bearing Assembly 1
8 204B0018 Flat Idler Pulley 1
9 PT0133 Wood Pillow Block Bearing, 7/8" Complete 2
10 PT0208 Bearing, Eccentric Lock, 7/8" 2
11 PT0228 Wood Bearing, 7/8" Bore 2
12 PT0400 Collar, 7/8" Set Screw Lock 1
13 PT0402 Collar, Eccentric Lock, 7/8" 2
14 PT0414 2 Holed Stamped Pillow Block 2
15 PT0611 Pulley, 2-1/2" x 7/8", Double Groove, A Section 1
16 1FH0765 Hex Nut, 3/8" 9
17 2FH0855 Hex Bolt, 3/8" x 1" 8
18 2FH1041 Hex Bolt, 3/8" x 5-1/2", Full Thread 1
19 3FH0561 Snap Ring, 5/8" 1
20 3FH0791 Lock Washer, 3/8" Medium 8
21 3FH0829 Machinery Bushing, 1-3/8" O.D. x 7/8" I.D. x 14 GA 1
22 3FH0864 Flat Washer, 5/16" 8
23 3FH0930 Spring Pin, 3/16" x 1-1/4" 1
24 3FH0952 Flat Washer, 5/8" SAE 3
Front Drum Bearing Rear Drum Bearing Double Bearing
