DMC HI-CAP 40 - Main Cleaner Parts

10
Parts List Hi-Cap 40 Grain Cleaner
Reference # Part # Description Qty Needed
1 10C30025 Extension Sprin
g
, Belt Ti
g
htene
r
1
2 202A0028 Inside Cone Screen Strap, 60-1/4" 1
3 202A0029 Inside Cone Screen Strap, 57-1/8" 1
4 202A0030 Inside Cone Screen Strap, 88-1/2" 1
5 202A0031 Outside Drum Screen Strap, 125-7/8" 7
6 202A0038 Screen, Inside Cone
(
Refer To Screen Selection Guide for Wire Size
)
2
7 202A0039 Screen, Trash Spout Section 1
8 202A0040 Screen, Outside Drum, Set of 1-24" Width and 1-36" Width 1
9 202A0042 Drum 1
10 202B0001 Frame End, Rea
r
1
11 202B0022
A
d
j
ustin
g
Le
g
, Front Frame 1
12 202B0025 Intake Pan 1
13 202B0034 Bracket, Dischar
g
e Shield 1
14 202B0035 Side Rail, Main Frame 2
15 202B0038 Belt Shield 1
16 202B0041 Dischar
g
e Shield 1
17 202B0044 Countershaft, 7/8" x 7-3/8" 1
18 202B0046 Belt Ti
g
htener, Drum Drive 1
19 202B0050 Bearin
g
Mount Extension Bracket 2
20 202B0051 Pivot Bolt, Belt Ti
g
htener Bracket, 3/8" 2
21 202B0052 Sprin
g
Tension Bracket 1
22 202B0057 Main Frame, Front 1
23 202E0003 Power Cord, Cleaner Moto
r
1
24 202E0008 Power Cord, To Au
g
er, 115 Volt 1
202E0005 Power Cord, To Au
g
er, 230 Volt 1
25 202E0009 Power Cord, Lead In, 115 Volt 1
205E0004 Power Cord, Lead In, 230 Volt 1
26 204B0018 Flat Idler Pulle
y
1
27 PT0108 Double Bearin
g
, Countershaft, 7/8" 1
28 PT0113 Drum Bearin
g
, Set Screw, 7/8" 2
29 PT0208 Bearin
g
, Eccentric Lock, 7/8" 2
30 PT0209 Bearin
g
, 7/8" 1
31 PT0402 Collar, Eccentric Lock, 7/8" 2
32 PT0417 Bearin
g
Housin
g
, Drum 1
33 PT0418 Bearin
g
Housin
g
, Double 1
34 PT0497 Belt, Motor Drive, A-55 1
35 PT0512 V-Belt, Drum Drive, 1-90
(
Matched Set
)
2
36 PT0605 Pulle
y
, Motor Drive, 5/8" x 2-1/4", A Section 1
37 PT0611 Pulle
y
, 2-1/2" x 7/8", Double Groove, A Section 1
38 PT0690 Pulle
y
, 7/8" x 14", A Section 1
39 MS0010 Wheel, 2-3/4" x 10" x 3/4" 2
40 1EL0401 Connector, 3/8", 115 Volt 3
1EL0401 Connector, 3/8", 230 Volt 4
1EL0403 Connector, 3/4", 115 Volt 1
41 1EL0667 Plu
g
, 125 Volt, 30 Amp 1
1EL0668 Plu
g
, 230 Volt, 20 Amp 1
42 1EL0673 Twist Connector, 125 Volt, 30 Amp 1
1EL0675 Twist Connector, 230 Volt, 20 Amp 1
43 2EL0320 Switch Box, 240 Volt, A.C., 30 Amp 1
44 3EL5064 Motor, 1/2 HP, TEFC, Electri
c
1
45 1FH0763 Hex Nut, 1/4" 17
46 1FH0764 Hex Nut, 5/16" 4
47 1FH0765 Hex Nut, 3/8" 23
48 1FH0767 Hex Nut, 1/2" 4
49 2FH0477 Self Tappin
g
Hex Screw, #10 x 3/4" 12
50 2FH0617 Square Head Set Screw, 3/8" x 3/4" 2
51 2FH0726 Round Head Machine Screw, 1/4" x 3/4" 7
52 2FH0735 Round Head Machine Screw, 1/4" x 2-1/2" 10
53 2FH0830 Hex Bolt, 5/16" x 1" 4
54 2FH0855 Hex Bolt, 3/8" x 1" 10
55 2FH0856 Hex Bolt, 3/8" x 1-1/4" 4
56 2FH0857 Hex Bolt, 3/8" x 1-1/2" 6
57 2FH1041 Hex Bolt, 3/8? X 5-1/2", Full Thread 1
58 3FH0561 Snap Rin
g
, 5/8" 1
59 3FH0730 Cotter Pin, 3/16" x 1-1/4" 2
60 3FH0789 Lock Washer, 1/4" 7
61 3FH0790 Lock Washer, 5/16" Medium 4
62 3FH0791 Lock Washer, 3/8" Medium 22
63 3FH0863 Flat Washer, 1/4" 8
64 3FH0864 Flat Washer, 5/16" 4
65 3FH0867 Flat Washer, 1/2" 4
66 3FH0930 Sprin
g
Pin, 3/16" x 1-1/4" 1
67 3FH0952 Flat Washer, 5/8" SAE 3
68 3FH0954 Flat Washer, 3/4" SAE 2
69 3FH0976 Cupped Washer, 7/8" O.D. x 17/64" 12
70 3FH0992 Woodruff Ke
y
, 3/16" x 1" 2
71 6FH001 Tornbuckle, 5/8" 1
MODEL 40 HI-CAP GRAIN CLEANER PARTS
