AssemblyHi-Cap 40 Grain Cleaner
Assembly Instructions (continued)
Step 19 Place the pan on the cleaner frame and attach to the side rails, using eight ¼” x ¾”
hex bolts, flat washers and hex flange lock nuts. See Photos 32 and 33.
Step 20 Bolt the front bearing mount extension bracket and wood bearing together using
two 3/8” x 1” hex bolts, 5/16” flat washers, lock washers and nuts. Next slide the
wood bearing and bracket onto the drum shaft then place a 7/8” x 14 gauge ma-
chinery bushing to he shaft and secure with 3/16” x 1-
1
/
4
” steel pin. Continue by
lacing the wood bearing to the rear drum shaft, secure with a 7/8” shaft collar.
Step 21 Place drum drive belts over the drum shaft inside cone screen as shown in Photo
34.
Step 22 Lay assembled cleaner frame on side, with motor up. Roll drum into the as-
sembled frame with belt drive ring on the same end as the electric motor. Using
two 3/8” x 1-
1
/
4
” bolts, lock washers and nuts, bolt the front bearing extension
bracket to the cleaner main frame as shown in Photos 35 and 36.
Step 23 Using two 3/8” x 1” hex bolts, 5/16” flat washers, lock washers and nuts, bolt the
rear wood drum bearing to the bearing extension plate. Finish by pulling the
screener drum toward the rear until the front bearing spring pin (feed in end) is
against front bearing. Complete by locking shaft collar against rear wood bearing.
See Photo 37, or wood bearing revisions on Page ????.
BE SURE DRUM DRIVE BELTS ARE POSITIONED AS OUTLINED IN STEP 20.
SET GRAIN CLEANER UP ON ITS WHEELS. BE SURE ALL BOLTS ARE TIGHT.
Step 24 Install A-90 belts over wooden idler, around 2-
1
/
2
” double groove pulley and onto
belt drive ring of drum. Finish by hooking belt tightener spring in position. See
Photo 38.
NOTE If trash pan equipped, install the A-112 belt to the 8” trash pan pulley, then to the
outer edge of drum drive ring. Adjust belt tension with flanged idler pulley. Attach
trash pan belt shield bracket using two ¼” x ¾” hex head bolts, lock washers and
nuts. Finish by bolting belt shield to bracket, using two ¼” x ¾” carriage bolts, flat
washers, lock washers and nuts. See Photos 39, 40 and 41.
Step 25 Bolt the discharge shield to the discharge shield bracket, using four ¼” x ¾” round
head machine screws, lock washers and nuts. See Photo 42.
Step 26 Bolt intake pan between small brackets on top of front frame, using two 3/8” x 1”
bolts, lock washers and nuts. See Photos 43 and 44.
