DMG Pitagora 4.0 - I;O Status and Configuration Menus

“I/O Status” Menu
----->>>>>
OR
----->>>>> ----->>>>>
Floor 0 - 12:30:56
< I/O Status >
Reset
SE3
Limit switch fault; you can clear it only after closing Safety chain.
Reset
82212
Drift control
Reset
RSP
RSP fault; for reduced pit and headroom.
Reset
UCM
UCM fault; for A3 amendment
Reset
ISO
ISO fault; problem detection in the operation monitoring of safety module for advanced door opening / re-
leveling.
Reset
SCS
SCS Fault; installation 81-20.
Reset
UAS
UAS Fault; Special function.
Table of Parameters:
Field Description Navigation Values (group of 12)
Car call
Simulation of a elevator
car call
▲▼ (Select floor)
ENTER (Confirm)
ESC (Exit)
Playboard IN-
OUT
System Inputs/Output
□ = Open Contact
■ = Closed Contact
▲▼ (Change
group)
ENTER (Exit)
ESC (Exit)
GROUPS
1/9
REM
VHS
SUR
RED
TH1
COM
REV
TH2
LE
REV1
REV2
LTMP
2/9
RMO
BRK
RDE
RGV
RMV
RPV
MTR
YBRK
CCF
CCO
CCOB
3/9
BRA
FOA
ROA
CEA
FFA
RFA
BRB
FOB
ROB
CEB
FFB
RFB
Table of Parameters
