DMG Pitagora 4.0 - Page 43

Cod. Parameter Description Navigation Values Default Value
C11
High
Speed
High speed for multistep speed change
(Only with FAI/FAS positioning system)
◄►
(Selection)
▲▼
(Change
value)
50 Hz
P01
Motor
Poles
Number of poles of the motor
◄►
(Selection)
▲▼
(Change
value)
4 (see motor data)
P02
Motor
Rated Cap
Rated power of the motor
◄►
(Selection)
▲▼
(Change
value)
Function of Inverter size
(see motor data)
P03
Motor
Rated Cur
Rated current intensity of the motor
◄►
(Selection)
▲▼
(Change
value)
Function of Inverter size
(see motor data)
P04
Motor
Autotuning
Auto tuning of motor parameters
(geared drives only)
◄►
(Selection)
▲▼
(Change
value)
0 (2 to trigger the auto
tuning procedure for geared
drives)
P06
M-No-
Load Curr.
Motor no-load current
◄►
(Selection)
▲▼
(Change
value)
Automatically set during
Auto tuning
P12
M-Rated
Slip
Rated slip frequency of the motor
◄►
(Selection)
▲▼
(Change
value)
0-
15Hz
Automatically set
L01 PG select See Annex IV
◄►
(Selection)
▲▼
(Change
value)
0-5
0 Geared drives
4 Gearless drives
L02
PG
resolution
Resolution of the pulse encoder (Pulse/
Turn)
◄►
(Selection)
▲▼
(Change
value)
360-
60000
P/R
1024 Geared drives
2048 Gearless drives
