D I S P L A Y
4,3" / 5"4,3" / 5"4,3" / 5"
PRG ADV
S2
S1
S3
TRIGGER
FAIL/RUN
POWER
SUPPLY
S4
LOP COP
12/24 Vdc
COP LIP/LOP
S1
S2
S3
CAR HERE
CUSTOM
Abilitare la segnalazione "Presente" da ingresso "NEXT DIR."
Enable "Car at Floor" signal from "NEXT DIR." input
4.4
Options
Interface Options
Car at Floor
PRG ADV
Programming MENU
No
Yes
Display Configuration
COP
LIP / LOP
Presente / Car at floor
NEXT
DIR.
SERIAL
INPUT
LP
LM
4S4S4S
OUT UP
S
OUT DOWN
NEXT DIR.
Presente / Car at floor
DK_RS_00M
Solo versione
con protocollo seriale
Serial protocol
version only
DK__SS00M
Impostare il gong indipendente dalla frecce
Set up the gong to be independent from arrows
4.5
Options
Interface Options
Gong with no Arrows
PRG ADV
Programming MENU
No
Yes
Solo versione con protocollo seriale
Serial protocol version only
DK__SS00M
Default
Gong
Gong
Arrows
Arrows
Impostare la velocità di trasmissione del protocollo CAN
Set up CAN BUS protocol trasmission speed
4.6
Options
Interface Options
CAN Baudrate
PRG ADV
Programming MENU
250 k
125 k
Solo versione con protocollo CAN BUS
CAN BUS protocol version only
DK__SC00M
Default
10 k
