All data sent onto the DALI bus are outrput as DALI Direct Arc Commands. Using the setup (see
below) these modes are available:
1. addressied Direct Arc Commands on a single DALI address
Preset: 4 addresses (A0...A3) = 4 DMX data slots, up to 64 addresses can be configured
2. addressierd Direct Arc Commands on a signle DALI gropu address
Preset: 4 groups (G0...G3) = 4 DMX data slots, up to 16 groups can be configured
3. unaddressed Direct Arc Command as Broadcast*
Preset: 1 address (1 DMX data slot)
*= pre-configured to 1 slot. When selection BROADCAST mode the slot count will automatically be decreased to just
one. Reverting to short addressed to to group mode may require re-set then slot count (see chapter „Setup“)
SETUP
On power up the operating parameters are read from memory. You may configure these parame-
ters at any time using these programming options and following this programming sequence:
SETUPM PROCEDURE:
Unpower the decoder. Set the required programming address (e.g. "889" for Single Address Set-
ting), then re-apply power. The command will be programmed into the interface, both status LEDs
are blinking alternatively several times. As soon as the programming sequence is completed,
upower the decoder, re-set the desired DMX start address and re-power the interface.
- Outputting DALI scene commands
Adresse: 885 This doubled the number of DMX data slots used, since each DALI address
uses the first fader as intensity control (ARC LEVEL) and the second fader
as scene control (scene 1...16)
- Outputting ARC LEVEL commands
Adresse: 886 All data are output as ARC LEVEL (default setting).
- Outputting DALI Broadcast-Kommandos
Adresse: 887 All data are output as DALI broadcast commands
In broadcast mode, the slot count will automatically be reduced to just 1.
- Outputting DALI GROUP commands
Address: 888 All data are output as DALI GROUP commands.
- Outputting DALI SINGLE ADDRESS commands
Address: 889 All data are output as DALI SINGLE ADRESS commands.
- Activating MASK value
Address: 890 The MASK value has been activated.
Data output is now from 000 (0%) to 254 (100%).
- Deactivating MASK value
Address: 891 The MASK value has been dectivated.
Data output is now from 000 (0%) to 255 (100%).
- Send DALI date in idle mode (automatic refresh)
Address: 892 DALI Data are output on DMX data change and on periodic refresh.
