User Manual C-6000i Computerized Jigging Reel
4
Main Parts of the Reel
On Figure 1 you can find the main parts of the jigging reel labeled with
number ranging from 1 to 14. The numbers refer to an explanation of the
function shown on next page. Numbers in parentheses indicate the page
where you can obtain more detailed information about any specific item.
Figure 1
1
