1. Adjust Preload knob to the top of the rear shock.
Following steps are for remove the spring from your shock
if your shocks are equipped with a longer version of rebound adjuster knob,
please remove the knob before remove the spring.
Using 1.5mm Allen key to remove it.
6. Tighten preload knob unl safety ring and spring are ght
5. Re-install the safety ring
2. Forward the spring unl there is space available for remove the safety ring
3. Remove the safety ring
4. Install or replace the spring, and do basic maintenance and cleaning
