TEST ACTION APPLICABILITY
12 Turn the ignition off.
Disconnect the Ignition Coil harness connector.
Disconnect the PCM harness connector.
Measure the resistance of the Ignition Coil driver circuit between the Ignition Coil
harness connector and the PCM harness connector.
Is the resistance below 5.0 ohms?
All
Yes → Go To 13
No → Repair the Ignition Coil driver circuit for an open.
Perform POWERTRAIN VERIFICATION TEST VER - 1.
13 Turn the ignition off.
Disconnect the Ignition Coil harness connector.
Disconnect the PCM harness connector.
Measure the resistance between ground and the Ignition Coil driver circuit in the
Ignition Coil harness connector.
Is the resistance below 100k ohms?
All
Yes → Repair the Ignition Coil driver circuit for a short to ground.
Perform POWERTRAIN VERIFICATION TEST VER - 1.
No → Go To 14
14 If there are no possible causes remaining, view repair. All
Repair
Replace and program the Powertrain Control Module in accor-
dance with the Service Information.
Perform POWERTRAIN VERIFICATION TEST VER - 1.
15 Turn the ignition off.
Disconnect the CKP Sensor harness connector.
Turn the ignition on.
Measure the voltage of the 5 Volt Supply circuit in the CKP Sensor harness connector.
Is the voltage between 4.8 and 5.2 volts?
All
Yes → Go To 16
No → Repair the 5 Volt Supply circuit.
Perform POWERTRAIN VERIFICATION TEST VER - 1.
16 Turn the ignition off.
Disconnect the CKP Sensor harness connector.
Turn the ignition on.
Measure the voltage of the CKP Sensor Signal circuit in the CKP Sensor harness
connector.
Is the voltage between 4.5 and 5.0 volts?
All
Yes → Go To 17
No → Go To 19
17 Turn the ignition off.
Disconnect the CKP Sensor harness connector.
Measure the resistance between ground and the Sensor Ground circuit at the CKP
Sensor harness connector.
Is the resistance below 100 ohms?
All
Yes → Go To 18
No → Repair the Sensor Ground circuit for an open.
Perform POWERTRAIN VERIFICATION TEST VER - 1.
319
STARTING
*ENGINE CRANKS DOES NOT START — Continued
To Next Page
