D O D G E B R A N D P R O D U C T I N F O R M A T I O N
2 0 0 5 D O D G E S P R I N T E R V A N
1 0
continued
DIMENSIONS AND CAPACITIES(a) (CONTINUED)
Cargo Van
2500 2500 High Roof 3500 3500 High Roof
Wheelbase 118 140 118 140 158 140 140 158
Track, Front 65.0 65.0 65.0 65.0 65.0 64.8 64.8 64.8
Track, Rear 64.8 64.8 64.8 64.2 64.2 61.1 61.1 61.1
Overall Length 197 225 197 225 263 225 225 263
Overall Width 76.1 76.1 76.1 76.1 76.1 78.3 78.3 78.3
Overall Height 93.1 94.7 102 103.6 103.6 94.5 103.3 102.7
Rear Load Height 26 28 26 28 28 28 28 27
Ground Clearance
Front axle 8.3 8.3 8.3 9.1 9.1 7.7 7.7 7.7
Rear axle 7.4 7.4 7.4 8.3 8.3 6.8 6.8 6.8
Rear Door Width 61.4 61.4 61.4 61.4 61.4 61.4 61.4 61.4
Width of Sliding
Door Opening 41.1 41.1 41.1 41.1 41.1 41.1 41.1 41.1
Approach Angle 22 26 22 26 26 22 22 22
Ramp Breakover Angle 15 13 15 16 15 14 14 13
Departure Angle 21 21 21 21 14 18 18 12
Drag Coefficient 0.34 0.34 0.36 0.36. 0.36 0.34 0.36 0.36
Fuel Tank Capacity
(gal./L) 26.4/100 26.4/100 26.4/100 26.4/100 26.4/100 26.4/100 26.4/100 26.4/100
Cargo Capacity 247 cu. ft. 321 cu. ft. 286 cu. ft. 367 cu. ft. 473 cu. ft. 321 cu. ft. 367 cu. ft. 473 cu. ft.
Payload Capacity
(lbs./kg) 4142/1879 3800/1724 4098/1859 3745/1699 3474/15761 5086/2307 5031/2282
4766/2162
Cab/Chassis
2500 3500
Wheelbase 140 158 140 158
Track, Front 65.0 65.0 64.8 64.8
Track, Rear 64.2 64.2 61.1 61.1
Overall Length 218 248 231 264
Overall Width 75.7 75.7 78.3 78.3
Overall Height 88.0 88.0 87.0 87.0
Ground Clearance
Front axle 9.1 9.1 7.7 7.7
Rear axle 8.3 8.3 6.8 6.8
Rear Door Width 61.4 61.4 61.4 61.4
Approach Angle 29 29 24 24
Ramp Breakover Angle 13 13 14 13
Departure Angle 30 23 13 11
Drag Coefficient 0.34 0.34 0.34 0.34
Fuel Tank Capacity (gal./L) 26.4/100 26.4/100 26.4/100 26.4/100
(a) All dimensions are in inches (millimeters) unless otherwise noted.
(b) Weight of body reduces available payload.
SPECIFICATIONS
