592
Practical hints
Fuses
5
No. Consumer Amp.
1 Horn 15 A
2 Electric steering lock ESTL
(electronic ignition switch
EIS)
25 A
3 Terminal 30 Z, vehicles
with gasoline engine/
electronic ignition switch
EIS
10 A
4 Light switch/center con-
sole switch unit
5A
5 Windshield wipers 30 A
6 Fuel pump 15 A
7 MRM (jacket tube mod-
ule)
5A
8 Terminal 87 (2) 20 A
No. Consumer Amp.
9 Terminal 87 (3) 20 A
10 Terminal 87 (4) 10 A
11 Terminal 15 R vehicle 15 A
12 Airbag control unit 10 A
13 Cigarette lighter/glove
box lighting/radio*
15 A
14 Diagnostic socket/light
switch/instrument cluster
5A
15 Front heating system* 5A
16 Terminal 87 (1) 10 A
17 Airbag control unit 10 A
18 Terminal 15 vehicle, brake
lamp switch
7,5 A
No. Consumer Amp.
19 Interior lights 7,5 A
20 Power window co-driver’s
side/terminal 30/2 signal
acquisition and actuation
module
25 A
21 Engine control unit 5A
22 Antilock Brake System
(ABS), brake lamp switch
5A
23 Starter motor 25 A
24 Diesel engine
components
10 A
25 12V socket on the bottom
of the center console
25 A
