Practical hints
Fuse Box in the Driver’s Seat
5
Fuse Box in th e Driver’ s Seat
Fuses
No. Consumer Amp.
1 Mirror adjustment*/rear
window heating*
5A
2 Rear window wiper* 30 A
3 Rear view camera*/tele-
phone*/pre-wiring mount-
ing slot (roof)*
5A
4 Operating speed governor
(ADR)*/PTO*/trailer con-
nection unit AAG*
7,5 A
5 Terminal 87 electronic
transmission control ETC,
control unit/automatic
transmission, control and
switch unit
10 A
6 Unassigned
7 Electronic selector level
module ESM
10 A
8 Terminal 15 body builder, drop
side/3-way tipper
10 A
9 Roof ventilator*/audio sig-
nal equipment*
15 A
10 Terminal 30, tapping wire
body builder
25 A
11 Terminal 15, tapping wire
body builder
15 A
12 D+, tapping wire body
builder
10 A
13 Air conditioning in the rear* 30 A
No. Consumer Amp.
14 Trailer socket* 20 A
15 Trailer recognition device* 25 A
16 Tire pressure monitoring
system (TPMS)*/Parktron-
ic system (PTS)*
7,5 A
17 PSM control unit* 25 A
18 PSM control unit* 25 A
19 Overhead control panel*/
sliding sunroof*
5/
25 A
20 Identification lamps* 7,5 A
21 Rear window
heating* 1
30 A
22 Rear window
heating* 2
15 A
No. Consumer Amp.
