Cavity Cartridge
Fuse
Mini-
Fuse
Description
M34 10 Amp
Red
Park Assist (PRK
ASST), Heater Venti-
lation, Air Condition-
ing Module (HVAC
MOD), Headlamp
Wash (HDLP WASH),
Compass (COMPAS)
M35 10 Amp
Red
Heated Mirrors
M36 20 Amp
Yellow
Power Outlet #3
(BATT)
M37 10 Amp
Red
Anti-Lock Brake Sys-
tem (ABS), Electronic
Stability Program
(ESP), Stop Lamp
Switch (STP LP SW),
Fuel Pump Rly Hi
Control
Cavity Cartridge
Fuse
Mini-
Fuse
Description
M38 25 Amp
Natural
Lock/Unlock Motors
(LOCK/UNLOCK
MTRS)
CAUTION!
•
When installing the integrated power module
cover, it is important to ensure the cover is prop-
erly positioned and fully latched. Failure to do so
may allow water to get into the integrated power
module, and possibly result in a electrical system
failure.
(Continued)
7
MAINTAINING YOUR VEHICLE 439
