Cavity Cartridge Fuse Mini-Fuse Description
14 – – Fuse – Spare
15 – 20 Amp Yellow Left HID – If Equipped
16 – 20 Amp Yellow Right HID – If Equipped
18 50 Amp Red – Radiator Fan #2 – (Non 6.2L Supercharged)
19 50 Amp Red – Electric Power Steering #2 – If Equipped / Ra-
diator Fan (6.2L Supercharged)
20 30 Amp Pink – Wiper Motor
21 30 Amp Pink
20 Amp Blue – Police
– Headlamp Washers – If Equipped
Police Bat Feed #2
22 40 Amp Green / 20
Amp Blue – Police
– Engine Cooling Pump (6.2L Supercharged) /
Police Bat Feed # 3
23 20 Amp Blue – Police Bat Feed # 1
24 20 Amp Blue – Police Ignition Run/ACC Feed # 3
28 – – Fuse – Spare
7
MAINTAINING YOUR VEHICLE 533
