Cavity Cartridge Fuse Mini-Fuse Description
39 – 10 Amp Red EPS (LA) / EHPS (Police)/AC Clutch Relay /
Vacuum Pump Relay / Fuel Pump Relay (LA)
/ Rad Fan Relays (LA)
48 – 10 Amp Red AWD Module (LD/LX) / Front Axle Disconnect
(LD/LX) / Adaptive Cruise (LA) – If Equipped
49 – – Fuse – Spare
50 – – Fuse – Spare
51 – 20 Amp Yellow Vacuum Pump
52 – 5 Amp Tan Adaptive Cruise (LD/LX) – If Equipped
53 – – Fuse – Spare
7
MAINTAINING YOUR VEHICLE 535
