Cavity Cartridge Fuse Mini-Fuse Description
33 – 15 Amp Blue Ignition Switch/RF Hub Module/Steering Col-
umn Lock (LX) – If Equipped
34 – 10 Amp Red Steering Column Module/Clock (LX)
35 – 5 Amp Tan Battery Sensor
36 – 15 Amp Blue Electronic Exhaust Valve – If Equipped
37 – 20 Amp Yellow Radio
38 – 20 Amp Yellow
Power Outlet Inside Arm Rest/Console Media Hub
40 – – Fuse – Spare
41 – – Fuse – Spare
42 30 Amp Pink – Rear Defrost
43 – 20 Amp Yellow Comfort Seat And Steering Wheel Module
(Heated Steering Wheel/RR Heated Seats)
44 – 10 Amp Red Park Assist / Blind Spot / Rear View Camera
45 – 15 Amp Blue Cluster / Rearview Mirror / Compass(LD/LX) /
Humidity Sensor
7
MAINTAINING YOUR VEHICLE 539
