Dodge Challenger 2012 - Page 443

Cavity Cartridge
Fuse
Mini-
Fuse
Description
12 * ———
13 * ———
14 — 10 Amp
Red
AC Heater Control/
Cluster/Security
Module – If
Equipped
15 — 20 Amp
Yellow
Active Damper – If
Equipped
16 — 20 Amp
Yellow
Heated Seat Module
– If Equipped
17 — 20 Amp
Yellow
Instrument Cluster
18 — 20 Amp
Yellow
Cigar Lighter (Instru-
ment Panel)
19 — 10 Amp
Red
Stop Lights
Cavity Cartridge
Fuse
Mini-
Fuse
Description
20 — — —
21 — — —
22 — — —
23 — — —
24 — — —
25 — — —
26 — — —
27 — 10 Amp
Red
Occupant Restraint
Controller (ORC)
28 — 10 Amp
Red
Ignition Run, AC
Heater Control/
Occupant Restraint
Controller (ORC)
7
MAINTAINING YOUR VEHICLE 441
