Cavity Cartridge Fuse Mini-Fuse Description
7 – – Fuse – Spare
8 20 Amp Blue – Police Ignition Run / ACC # 2
9 – 20 Amp Yellow All-Wheel Drive Module – If Equipped
10 – 10 Amp Red Security – If Equipped / Under hood
Lamp – Police
11 – 20 Amp Yellow Horns
12 – 10 Amp Red Air Conditioning Clutch
13 – – Fuse – Spare
14 – – Fuse – Spare
15 – 20 Amp Yellow Left HID – If Equipped
16 – 20 Amp Yellow Right HID – If Equipped
18 50 Amp Red – Radiator Fan #2 – If Equipped
19 50 Amp Red – Power Steering #2 / Radiator Fan
(6.2L Supercharged)
20 30 Amp Pink – Wiper Motor
532 MAINTAINING YOUR VEHICLE
