Cavity Cartridge Fuse Mini-Fuse Description
11 30 Amp Pink – Passenger Door Control
Module
12 – 20 Amp Yellow Dual USB Center Console
Rear/Cigar Lighter IP – If
Equipped
15 40 Amp Green – HVAC Blower
16 20 Amp Blue – Left Spot Lamp – Police
17 20 Amp Blue – Right Spot Lamp – Police
18 30 Amp Pink – Mod Network Interface –
Police
19 – – Fuse – Spare
20 – – Fuse – Spare
21 30 Amp Pink – Fuel Pump (Non 6.2L SRT
Demon)
22 – 5 Amp Tan Cyber Gateway Mod
23 – 10 Amp Red Fuel Door/Diagnostic Port
24 – 10 Amp Red Integrated Center Stack
25 – 10 Amp Red Tire Pressure Monitor
7
IN CASE OF EMERGENCY 285
