Cavity Cartridge Fuse Mini-Fuse Description
18 30 Amp Pink — Mod Network Interface – Police
19 — — Fuse — Spare
20 — — Fuse — Spare
21 30 Amp Pink (6.2L
Supercharged)
25 Amp Clear (LD STD)
— Fuel Pump (6.2L Supercharged)
Fuel Pump (LD STD)
22 — 20 Amp Yellow – Police
10 Amp Red – LA
Right Spot Lamp – Police
Integrated Center Stack – LA
23 — 10 Amp Red Fuel Door/Diagnostic Port
24 — 15 Amp Blue Integrated Center Stack – LD/LX
25 — 10 Amp Red Tire Pressure Monitor
26 — 15 Amp Blue – LD/LX
25 Amp Clear – LA
30 Amp Green – LA 6.2L
Supercharged
Transmission / Electronic Shift Mod-
ule (LD/LX)
Fuel Pump (LA)
Fuel Pump (LA 6.2L Supercharged)
27 — 25 Amp Clear Amplifier – If Equipped
518 MAINTAINING YOUR VEHICLE
