Cavity Cartridge
Fuse
Mini-
Fuse
Description
5 30 Amp
Pink
— Heated Seats – If
Equipped
6 — 20 Amp
Yellow
Fuel Pump
7 — 15 Amp
Blue
Audio Amplifier – If
Equipped
8 — 15 Amp
Blue
Diagnostic Link Con-
nector (DLC)/
Wireless Control
Module (WCM)/
Wireless Ignition
Node (WIN)
9 — 20 Amp
Yellow
Power Outlet
10 — 25 Amp
Natural
Vacuum Pump – If
Equipped
11 * ———
Cavity Cartridge
Fuse
Mini-
Fuse
Description
12 * ———
13 * ———
14 — 10 Amp
Red
AC Heater Control/
Cluster/Security
Module – If
Equipped
15 — — —
16 — 20 Amp
Yellow
Heated Seat Module
– If Equipped
17 — 20 Amp
Yellow
Instrument Cluster
18 — 20 Amp
Yellow
Cigar Lighter (Instru-
ment Panel)
19 — 10 Amp
Red
Stop Lights
20 — — —
7
MAINTAINING YOUR VEHICLE 423
