The vehicle is close to the obstacle when the
warning display shows one flashing arc and
sounds a continuous tone. The following chart
shows the warning alert operation when the
system is detecting an obstacle:
WARNING ALERTS
Rear Distance
(inches/cm)
Greater than
79 inches
(200 cm)
79-59 inches
(200-150 cm)
59-47 inches
(150-120 cm)
47-39 inches
(120-100 cm)
39-25 inches
(100-65 cm)
25-12 inches
(65-30 cm)
Less than
12 inches
(30 cm)
Audible Alert
Chime
None Single 1/2
Second Tone
Slow Slow Fast Fast Continuous
Arcs-Left None None None None None 2nd
Flashing
1st
Flashing
Arcs-Center None 6th Solid 5th Solid 4th Solid 3rd
Flashing
2nd
Flashing
1st
Flashing
Arcs-Right None None None None None 2nd
Flashing
1st
Flashing
Radio Volume
Reduced
No Yes Yes Yes Yes Yes Yes
Fast Tone Continuous Tone
180
