Power Distribution Center - Relays and Fuses
Figure 8 - 505
ITEM
P ART
NUMBER
QTY
LINE
SERIES BODY ENGINE TRANS
TRIM
DESCRIPTION
Power Distribution Center - Relays and Fuses
1 050591 12AB 1
POWER DISTRIBUTION
CENTER, Serviced in Headlamp to
Dash Harness, (NOT SER VICED)
2 04638094 1
RELA Y P ACKAGE, Electrical,
Headlamp W asher , Radiator Fan,
Automatic Shutdown
3 04671 168 1 RELA Y , Mini, Fuel Pump, Wipers,
Starter . Rear Fog Lamps
4 000A TM20 1
C
H, M
FUSE, Mini, 20 AMP , Y ellow
5
FUSE CAR TRIDGE, 30 Amp
06102076AA 1
C
H, M
1 D
1
C
P
6
FUSE CAR TRIDGE, 40 Amp
06102077AA 1
C
H, M
1
C
P
1 D
1 Y
7
FUSE CAR TRIDGE, 50 Amp
06102078AA 1
C
H, M
1 Y
1 D
1
C
P
-8 04760691 1
BRACKET , Power Distribution
Center
-9 04760134AE 1
COVER, Power Distribution Center
10
000A TC20
1
C
H, M
FUSE, Standard, 20 Amp, Y ellow
1 1
000A TC30
1
C
H, M
FUSE, Standard, 30 Amp, Light
Green
-12 04606418AA 1 RELA Y , Electrical
-13 04671 168 1 RELA Y , Mini
CONCORDE,INTREPID,VISION,300M,NEW YORKER,LHS (LH)
SERIES
LINE
BODY ENGINE TRANSMISSION
P = Limited
S = 300M
H = SE
M = LXI
X = 300M Special
C = Concorde
E = 300M
H = Chrysler Intrepid
D = Dodge Intrepid
41 = 4 Door Sedan EER = Engine - 2.7L V6 DOHC
24 V alve MPI
EGC = Engine - "Magnum"
3.5L V6 SOHC 24V
EGG = Engine - 3.5L High
Output V6 24V MPI
EGJ = Engine - 3.5L V6 SOHC
24 V alve
EGK = Engine - 3.5L High
Output V6 24V MPI
DGX = T ransmission - 4 -Speed
Automatic
DG0 = All Automatic T ransmissions
AR = use ase required - = Non illustrrated part
2004 LH
<< RETURN T O GROUP INDEX
