Engine/
Transmission
Model Frontal Area Max GTW (Gross Trailer
Wt)
Tongue Wt. (See Note)
3.7L/Automatic
w/Trailer Tow
Package
4x2 64 sq ft (5.94 sq m) 5,000 lbs (2 268 kg) 500 lbs (227 kg)
3.7L/Automatic
w/Trailer Tow
Package
4x4 64 sq ft (5.94 sq m) 5,000 lbs (2 268 kg) 500 lbs (227 kg)
4.0L/Automatic
w/Trailer Tow
Package
4x2 64 sq ft (5.94 sq m) 5,000 lbs (2 268 kg) 500 lbs (227 kg)
4.0L/Automatic
w/Trailer Tow
Package
4x4 64 sq ft (5.94 sq m) 5,000 lbs (2 268 kg) 500 lbs (227 kg)
Refer to local laws for maximum trailer towing speeds.
NOTE: The trailer tongue weight must be considered as
part of the combined weight of occupants and cargo, and
should never exceed the weight referenced on the tire
and loading information placard. Refer to “Tire Safety
Information” in “Starting and Operating” for further
information.
364 STARTING AND OPERATING
