Cavity Cartridge
Fuse
Mini-
Fuse
Description
J9 40 Amp
Green
PZEV Motor/Flex
Fuel
J10 30 Amp
Pink
Hdlp Wash Relay/
Manual Tuning Valve
J11 30 Amp
Pink
Sway Bar/
THATCHAM Lock-
Unlock/Power Slid-
ing Door Module
J13 60 Amp
Yellow
Ignition Off Draw
(IOD) – Main
J14 40 Amp
Green
EBL (Rear Window
Defogger)
J15 30 Amp
Pink
Rear Blower
J17 40 Amp
Green
Starter Solenoid
Cavity Cartridge
Fuse
Mini-
Fuse
Description
J18 20 Amp
Blue
Powertrain Control
Module (PCM) Trans
Range
J19 60 Amp
Yellow
Radiator Fan
J20 30 Amp
Pink
Front Wiper LO/HI
J21 20 Amp
Blue
Front/Rear Washer
J22 25 Amp
Natural
Sunroof Module
M1 15 Amp
Blue
Center High Mounted
Stop Light (CHMSL)/
Brake Switch
M2 20 Amp
Yellow
Trailer Lighting
7
