Cavity Maxi Fuse Mini Fuse Description
Starter Relay Coil (3.0 Diesel Engine)
F17 – 20 Amp Yellow Engine Control Module (ECM), Injectors
(3.6 Gasoline Engine)
F17 – 20 Amp Yellow Secondary Loads, Engine Control
Module (ECM) (3.0 Diesel Engine)
F18 – 7.5 Amp Brown KL30 Engine Control Module (ECM),
KL30 Main Relay Coil (3.6 Gasoline
Engine)
F18 – 7.5 Amp Brown KL30 Manual Transmission Automated
(MTA), KL30 Engine Control Module
(ECM), KL30 Main Relay Coil
(3.0 Diesel Engine)
F19 – 7.5 Amp Brown A/C Compressor (If Equipped)
F20 – 30 Amp Green Windshield Wiper
F21 – 15 Amp Blue Fuel Pump
F22 – 20 Amp Yellow Engine Control Module (ECM), Ignition
