Cavity Cartridge Fuse Mini-Fuse Description
14 – – Fuse – Spare
15 – 20 Amp Yellow Left HID – If Equipped
16 – 20 Amp Yellow Right HID – If Equipped
18 40 Amp Green – Radiator Fan #2 – If Equipped
19 50 Amp Red – Power Steering #2 / Radiator Fan
(6.2L Supercharged)
20 30 Amp Pink – Wiper Motor
21 20 Amp Blue – Headlamp Washers – If Equipped / Police
Feed
22 40 Amp Green /
20 Amp Blue – Po-
lice
– Engine Cooling Pump (6.2L Supercharged)
/ Police Bat Feed#3–IfEquipped
23 20 Amp Blue – Police Bat Feed#1–IfEquipped
24 20 Amp Blue – Police Bat Feed#3–IfEquipped
28 – – Fuse – Spare
7
