Cavity Cartridge Fuse Mini-Fuse Description
23 — 10 Amp Red Fuel Door/Diagnostic
Port
24 — 15 Amp Blue Integrated Center Stack –
LD/LX
25 — 10 Amp Red Tire Pressure Monitor
26 — 15 Amp Blue – LD/LX
25 Amp Clear – LA
30 Amp Green – LA 6.2L
Supercharged
Transmission / Electronic
Shift Module (LD/LX)
Fuel Pump (LA)
Fuel Pump (LA 6.2L Su-
percharged)
27 — 25 Amp Clear Amplifier – If Equipped
31 — 25 Amp Breaker Power Seats
32 — 15 Amp Blue HVAC Module/Cluster
33 — 15 Amp Blue Ignition Switch/RF hub
Module/Steering Column
Lock-LX If Equipped
7
MAINTAINING YOUR VEHICLE 537
