DOLOMITE JAZZ
BRAKES
G. Apply the brakes by pulling both brake
handles upwards.
PARKING BRAKE
H. Press the brake handles carefully down-
wards to apply the parking brakes. A
distinct click indicates that the brake is in
the correct position. It is important that
both brakes are put into parking position.
To release the brake pull the brake hand
le upwards. Both brakes must be in the
parking position when you are sitting in
the rollator.
ADJUSTMENT OF
BRAKE EFFECT
I. If braking effect is poor adjust the brake
cable. Suitable tools to use are fixed spa-
nners, 7 and 10 mm (not included).
HANDLEBARS
For height adjustment of handle.
J. Stand behind the rollator.
The handles should normally be positioned
at wrist height.
K. Loosen the handlebar using the knob
and adjust to a suitable height. Lock the
handlebars using the knob. Check that
both handles are set at the same height.
G
H
I
J
K
