8
3. Push both brake assemblies onto rear leg tubes at
the same time until spring loaded buttons click into
NOTE: If brake assemblies do not click and hold in place, the spring button
stuck not protruding through the hole in the tube. Use a
screwdriver or pliers to move the button so that it protrudes out of the hole
in the tube.
Slide Rear Wheel onto axle.
5.
Slide Washer onto axle.
6.
Fit the straight part of the Cotter Pin
through hole on axle as shown.
Line up tabs in the Hub Cap with slots in
the wheel, snap hub cap into place.
Repeat for second side.
To Next Page
