4445103633 13
Description of the device
Control and display elements
Compressor and error indicator LED
The compressor and error indicator LED displays
the operating status of the compressor or indicates
an error:
Operation mode indicator LEDs
The operation mode indicator LEDs display the fol-
lowing setting options:
No in
fig. 1,
page 3
Explanation
1 Door shelf
2 Bottle shelf
3 Condensate drain
4Crisper
5 Cabinet shelf
6 Control panel with display
7 Frozen compartment
8 Door latch for ventilation
No in
fig. 2,
page 3
Explanation
1 IR door opening sensor
2
ON/OFF button
3
Cooling level setting button
4 Compressor and error indicator LED
5
Operation mode button
6 Interior lighting
7 Cooling level indicator LEDs
Cooling Level 5
Cooling level 4
Cooling level 3
Cooling level 2
Cooling level 1
8 Operation mode indicator LEDs
Color Description
White Compressor on
Orange Compressor off
Orange
(flashing)
Error (chapter “Error indication” on
page 19)
Symbol Description
ECO mode:
Operation with reduced energy
consumption.
Cooling level 1 – 3
QUIET mode:
Operation with reduced noise level.
Cooling level 1 – 4
PERFORMANCE mode
Cooling level 1 – 5
FREEZER mode :
Operation with frozen compartment
removed. Cools down the complete
interior of the refrigerator to – 6 °C
WINTER mode (only NRX1115–1130):
To ensure adequate cooling of the frozen
compartment at low ambient tempera-
tures.
