CRE Installing and connecting the refrigerator
21
7.4 Installing the refrigerator
Proceed as follows to install the refrigerator:
➤ If you wish to drain the condensate through a hose:
Mount the outlet port (see chapter “Mounting the outlet port (optional)” on
page 20)
➤ Undo the transport lock (chapter “Releasing the lock” on page 26).
➤ Open the refrigerator door.
➤ Remove the blanking plugs (fig. 7 2, page 5).
➤ Push the refrigerator into the recess.
➤ Fix the refrigerator in place using suitable screws (fig. 7 1, page 5).
➤ Press the blanking plugs (fig. 7 2, page 5) into the openings.
7.5 Changing the door hinge
You can change the hinge of the door, so that it opens to the left rather than the right.
➤ Proceed as shown in fig. 8, page 6 to fig. 9, page 6, to change the hinges.
7.6 Replacing the door panel
A
The decorative trim has the following measurements (see fig. 0, page 7):
Removing and installing the decorative trim
➤ Proceed as shown (fig. a, page 7 to fig. c, page 9) to remove the decorative
trim.
➤ Proceed in reverse sequence to install the decorative trim.
NOTICE! Risk of damage!
The door panel must be replaced only when the refrigerator is upright.
Model A B C
CRE0050 350 ± 0.5 mm 474 ± 0.5 mm
0.5 mmCRE0065 419 ± 0.5 mm 468 ± 0.5 mm
CRE0080 445 ± 0.5 mm 582 ± 0.5 mm
