3.4 Description of components
9
Description of model
Level indicator / flush (control panel)
Wall socket console
Removable seat
Ceramic toilet bowl
Emptying blade for the toilet bowl
Housing for cassette tank
Fresh water tank (option)
Pour out spout
Vent button for emptying
Pull-out handle (cassette tank movable on wheels)
Service door
2
1
3
4
5
6
7
8
9
10
11
Fig. 3
1
7
8
2
3
4
5
6
9
5
10 11
