D15, D50, D52 Technical description
15
Controls:
No. in
fig. 2,
page 4
Symbol Description
1 On/off switch
2
D15, D50: Increases the set temperature of the upper
temperature zone by 1 °C or 1 °F
D52: Increases the set temperature by 1 °C or 1 °F
3
D15, D50: Reduces the set temperature of the upper
temperature zone by 1 °C or 1 °F
D52: Reduces the set temperature by 1 °C or 1 °F
4
D15, D50: Display indicates the current temperature of the upper
temperature zone
D52: Display indicates the current temperature
5
D15, D50: Display indicates the current temperature of the lower
temperature zone
6
D15, D50: Increases the set temperature of the upper
temperature zone by 1 °C or 1 °F
7
D15, D50: Reduces the set temperature of the lower temperature
zone by 1 °C or 1 °F
8 Switches the interior light on or off
