Dometic IBIS4 Series User Manual

15
AU
IBIS4 Installation
See fig. b
➤ Orientate roof frame based on opening size.
➤ Fit the roof frame into the roof opening
➤ Seal around the roof frame with flexible non-hardening butyl sealing com-
pound (e.g. SikaLastomer-710, Selleys Butyl Mastic, Bostik ezycaulk butyl
sealant, or similar products).
See fig. c
➤ Lift the roof air conditioner onto the roof of the vehicle.
➤ Position the roof air conditioner onto the roof plate and align into the groove
in the base pan.
Observe the direction of travel.
b
c
IBIS4-A4--I.book Seite 15 Mittwoch, 13. März 2019 9:43 21
