BEFORE CLEANING THE APPLIANCE ALWAYS TURN IT OFF AND DISCONNECT
FROM POWER SUPPLY AND WAIT UNTIL IT HAS COOLED DOWN.
SURFACES THAT ARE STILL HOT CAN BE DAMAGED IF THEY COME INTO
CONTACT WITH COLD WATER OR A DAMP CLOTH.
NEVER USE ABRASIVE, CORROSIVE OR CHLORINE BASED CLEANING PRODUCTS.
NEVER USE STEEL OR PLASTIC SCOURING PADS. NEVER LEAVE DEPOSITS OF
ACID OR ALKALINE SUBSTANCES (VINEGAR, SALT, LEMON JUICE ETC.) ON THE
APPLIANCE. STAINLESS STEEL OR ENAMELLED SURFACES MUST BE CLEANED
ONLY WITH WATER AND SOAP OR A NEUTRAL DETERGENT, THOROUGHLY
RINSE AND DRY. USE CLEAN SPONGES OR CLOTHS TO CLEAN.
INJECTORS
CLEANING OR REPLACING GAS INJECTORS MUST ONLY BE PERFORMED BY
AUTHORISED AND QUALIFIED GAS SERVICE ENGINEERS. THE MANUFACTURER
DECLINES ALL RESPONSIBILITY IN REGARD.
CLEANING
BURNER
Ø INJECTOR (mm)
SEMI-RAPID
Ø 62 mm
STAMPED N.
AUXILIARY
Ø 47 mm
0,50
0,45 ( MOD. PI7903T - PI7923T )
50
45 ( MOD. PI7903T - PI7923T )
RAPID
Ø 77 mm
0,75 75
TEST PRESSURE POINT (IF FITTED)
THE TEST PRESSURE POINT (PRESSURE CHECK VALVE) IS FITTED UNDER THE HOB. (FIG. 4 - PG. 149).
Removing and mounting this test pressure point (pressure check valve) must be performed by a qualied gas service
engineer. Gas pressure is related to the type of gas used to supply the appliance. Refer to chapter GAS in this manual.
When removing and mounting the injectors the injector holder must be must be held in place with the aid of a tool
(FIG. 5 - PAG. 150).
0,67
0,64 ( MOD. HBH1303ILG/IRG )
67
64 ( MOD. HBH1303ILG/IRG )
