MAINTENANCE INSTALLATIONUSE
AUXILIARY
Ø 47 mm
from 6 to 16 cm
SEMI-RAPID
Ø 62 mm
from 16 to 22 cm
from 10 to 16 cm (MOD. HBH1303ILG/IRG)
RAPID
Ø 77 mm
from 16 to 22 cm
BURNER PAN DIAMETER
19
ENGLISH
To ignite burner, gently push-in and turn the control knob to position HIGH FLAME and maintaining the knob pushed
at the same time press the electronic ignition pushbutton. Once the burner is alight maintain the knob in this position
for a few seconds to the ensure the flame remains alight.
-MANUAL IGNITION HOB
- SELECTING BURNER
- ELECTRONIC IGNITION HOB (DEPENDING ON MODEL)
HOB
Manual ignition when the appliance is not fitted with the electronic ignition feature or in the event of failure in the
electronic ignition.
MAKE SURE THERE ARE NO PANS OR OTHER ANY OBJECTS ON THE BURNERS
WHEN IGNITING.
IF THE BURNER DOES NOT IGNITE IMMEDIATELY REPEAT IGNITION AFTER
HAVING FOLLOWED EACH STEP BELOW:
• TURN THE KNOB TO “SMALL FLAME”
• PROCEED WITH MANUAL IGNITION
• CHECK THERE IS SUFFICIENT GAS IN THE GAS BOTTLE.
IF THE APPLIANCE STILL DOES NOT IGNITE SHUT OFF THE GAS SUPPLY AT
THE MAIN GAS TAP AND CONTACT YOUR LOCAL DEALER.
MAKE SURE THERE ARE NO PANS OR OTHER ANY OBJECTS ON THE BURNERS WHEN IGNITING.
To ignite burner, gently push-in and turn the control knob to position HIGH FLAME and maintaining the knob pushed at
the same time light the burner with a match or gas lighter. Once the burner is alight maintain the knob in this position
for a few seconds to ensure the flame remains alight.
IF THE BURNER DOES NOT IGNITE IMMEDIATELY CHECK THERE IS
SUFFICIENT GAS IN THE GAS BOTTLE.
IF THE APPLIANCE STILL DOES NOT IGNITE SHUT OFF THE GAS SUPPLY AT
THE MAIN GAS TAP AND CONTACT YOUR LOCAL DEALER.
- HOB FLAME REGULATION
To regulate flame turn the knob to the desired cooking flame.
THE FLAME MUST NEVER EXTEND BEYOND THE EDGE OF THE PAN. CENTRE
THE PAN OVER THE BURNER ENSURING STABILITY ON THE PAN SUPPORT.
