RC10.4 70, RC10.4 90 Setting up and connecting the refrigerator
21
Key for fig. 9, page 8
A
•
Before starting the device for the first time, check whether the operating voltage
and the battery voltage correspond (see type plate).
➤ Connect the cooling device
– As directly as possible to the pole of the battery or
– To a plug socket which is fused with at least 15 A (at 12 V) or 7.5 A (at 24 V).
A
The cooling device is equipped with an electronic device to protect against
reversing the polarity and short circuits when connecting to a battery. To protect the
battery, the cooling device switches off automatically if the voltage is insufficient
(see table below).
Connecting to AC mains supply
D
Co-ordinate axis Meaning Unit
l Cable length m
∅ Cable cross section mm²
NOTICE!
Make sure that the polarity is correct.
NOTICE!
Disconnect the cooling device and other power consuming devices
from the battery before connecting the battery to a quick charging
device.
Overvoltage can damage the electronics of the device.
12 V 24 V
Switch-off voltage
10.4 V 22.8 V
Switch-on voltage
11.7 V 24.2 V
DANGER!
•
Never handle plugs and switches with wet hands or if you are
standing in a puddle.
•
If you are operating your cooling device on board a boat with
a mains connection from the land, you must install a ground protec-
tion circuit breaker between the AC mains supply and the cooling
device.
Seek advice from a trained technician.
RC10.4-IO-EN-DE-FR-NL.book Seite 21 Montag, 10. September 2018 11:15 11
