Installing the refrigerator RC(S)(L)(D)10-Series
14
4.1 Preparing the installation
!
A
I
When installing the refrigerator, note the following:
• Ensure that the floor is solid and level.
Park the vehicle horizontally for this purpose.
• The refrigerator must be installed so that
– it is easily accessible for service work
– easy to uninstall and install
– can be easily removed from the vehicle
• The refrigerator must be installed in a recess so that it stands secure when the
vehicle is in motion. Note the dimensions in fig. 1, page 3
to fig. 3, page 5 for
this purpose.
• The refrigerator must be installed with a minimum distance of 5 mm from the floor
to ensure that the door can be opened properly (fig. 5, page 6).
– Make sure that no carpets interfere with the free movement of the door.
– Avoid placing the refrigerator directly on the floor.
• Also note the following recess dimension (fig. 4, page 5):
CAUTION! Risk of injury
The device has sharp edges and gloves should be used during installa-
tion.
NOTICE! Damage hazard
• The refrigerator may not be installed in the rear of mobile homes with
the door pointing in the direction of travel.
• Leave the device in a vertical position for at least 3 hours before start-
ing up for the first time.
NOTE
• In campervans an undercounter unit can be installed with the door
pointing in the direction of travel, as long as it is installed next to the
sliding door and behind the co-driver’s seat.
• If the compressor fridge replaces an absorption unit, you have to
make sure, that the external ventilation grills are completely closed,
otherwise there is the risk, that the compressor will not run at low
ambient temperature (~below 0 °C).
RC10.4(S)(T).70 RC10.4(S)(T).90
Refrigerator height (A) 821 mm 975 mm
Refrigerator width (B) 420 mm 420 mm
